Fenix HM75R Magnesium Dual Battery Rechargeable Headlamp
Magnesium Dual Battery Rechargeable Headlamp
The Fenix HM75R is a professional-grade rechargeable headlamp designed for industrial and search-and-rescue operations. It delivers a maximum output of 1600 lumens with a beam distance of 223 meters, powered by two lithium-ion batteries—ARB-L21-5000 V2.0 and ARB-L18-3400. This headlamp offers a remarkable runtime of 234 hours on its lowest setting. Its dual-switch design includes a rotary switch for power and mode selection, complemented by an electronic switch for output levels. The magnesium alloy construction meets IP68 standards for waterproofing and is impact-resistant to 2 meters. The separation design with a 1-meter extension cable enhances usability and comfort.
Key Features
- 1600 lumens maximum output, 223 meters maximum beam distance.
- One Luminus SST40 cold white LED, two Luminus SST20
- neutral white LEDs, and one OSRAM GR QSSPA1.23 red light LED; with a life span of 50,000 hours each.
- Two power sources for ultimate convenience.
- Made of high-quality magnesium alloy material,light weight and durable.
- Rotary switch and electronic switch for easy and fast operation.
- Spotlight, floodlight and red light combined.
- Intelligent brightness downshifting function to avoid potentially dangerous high temperature(s) at close-range lighting.
- The USB Type-C port on the battery case supports fast-discharging.
- The power extender features a quick-release structure for various wearing ways, and can be used as an emergency power bank.
- Two USB Type-C ports with inner waterproofing treatment.
Specifications
| Waterproof Rating | IP68 |
| Impact Resistance | 2m |
| Size — Length | Length: 91.1 mm |
| Size — Width | Width: 41 mm |
| Size — Height | Height: 53.5 mm |
| Weight — Including batteries | 321 gm, including batteries |
| Battery | Two ARB-L18-3400 and ARB-L21-5000 Li-ion Rechargeable Batteries. Included. |
| Output Modes | 12 |
Performance Data
| Mode | Output (lumens) | Runtime | Distance | Intensity |
|---|---|---|---|---|
| SPOT TURBO | 1,600 | 9h | 223m | 12448 cd |
| SPOT HIGH | 800 | 10h 30min | 158m | 6262 cd |
| SPOT MED | 350 | 18h 20min | 101m | 2559 cd |
| SPOT LOW | 50 | 88h 40min | 39m | 383 cd |
| FLOOD TURBO | 1,000 | 13h | 60m | 1071 cd |
| FLOOD HIGH | 400 | 14h | 43m | 432 cd |
| FLOOD MED | 150 | 18h | 25m | 163 cd |
| FLOOD LOW | 5 | 234h | 5m | 10 cd |
| RED HIGH | 120 | 19h 40min | 16m | 70 cd |
| RED MED | 30 | 46h 20min | 9m | 20 cd |
| RED LOW | 5 | 256h | 4m | 4 cd |
| RED FLASH | 5 | 530h |
What's in the Box
- ARB-L18-3400 battery
- ARB-L21-5000 V2.0 battery
- 1 meter extension cable
- 2 x spare O-rings
Accessories for Fenix HM75R
Fenix APB-30
Fenix ARB-L18-4000
Fenix ARB-L21-5000 V2.0
Fenix ARE-D2
Fenix ARE-A2
